VR9-300HX15Z High Performance Cross Roller Guide for Machine Tool

  • JAPAN

  • THK

  • VR9-300HX15Z

  • IN STOCK

  • High precision

  • international standard

Availability:
Quantity:


THK Cross Roller Guide VR9-300HX15Z / V9-300



Model: VR9-300HX15Z Brand: THK
Country of Manufacture: Japan



Model No.

Maxstroke Main dimensions No.ofrollersZ Per-missiblepreloadδ Basic load rating(per roller) Rail mass
Combined dimensions Mounting dimensions

M A L0 n×F G B C S d D h T Da R g P CZ CZ0
mm mm mm mm mm mm mm mm mm mm mm mm mm mm mm mm mm μm kN kN kg/m
VR1‑20H×5Z 12 8.5 4 20 1×10 5 3.9 1.8 M2 1.65 3 1.4 1.6 1.5 14 2 2.5 5 –2 0.152 0.153 0.11
VR1‑30H×7Z 22 30 2×10 19 7
VR1‑40H×10Z 27 40 3×10 26.5 10
VR1‑50H×13Z 32 50 4×10 34 13
VR1‑60H×16Z 37 60 5×10 41.5 16
VR1‑70H×19Z 42 70 6×10 49 19
VR1‑80H×21Z 52 80 7×10 54 21
VR2‑30H×5Z 18 12 6 30 1×15 7.5 5.6 2.5 M3 2.55 4.4 2 1.5 2 21 2.5 4 5 –3 0.276 0.271 0.23
VR2‑45H×8Z 24 45 2×15 33 8
VR2‑60H×11Z 30 60 3×15 45 11
VR2‑75H×13Z 44 75 4×15 53 13
VR2‑90H×16Z 50 90 5×15 65 16
VR2‑105H×18Z 64 105 6×15 73 18
VR2‑120H×21Z 70 120 7×15 85 21
VR2‑135H×23Z 84 135 8×15 93 23
VR2‑150H×26Z 90 150 9×15 105 26
VR2‑165H×29Z 96 165 10×15 117 29
VR2‑180H×32Z 102 180 11×15 129 32
VR3‑50H×7Z 28 18 8 50 1×25 12.5 8.3 3.5 M4 3.3 6 3.1 2 3 36 3 5 7 –4 0.639 0.611 0.45
VR3‑75H×10Z 48 75 2×25 51 10
VR3‑100H×14Z 58 100 3×25 71 14
VR3‑125H×17Z 78 125 4×25 86 17
VR3‑150H×21Z 88 150 5×25 106 21
VR3‑175H×24Z 108 175 6×25 121 24
VR3‑200H×28Z 118 200 7×25 141 28
VR3‑225H×31Z 138 225 8×25 156 31
VR3‑250H×35Z 148 250 9×25 176 35
VR3‑275H×38Z 168 275 10×25 191 38
VR3‑300H×42Z 178 300 11×25 211 42
VR4‑80H×7Z 58 22 11 80 1×40 20 10.2 4.5 M5 4.3 8 4.2 2 4 51 4.5 7 7 –5 1.38 1.35 0.8
VR4‑120H×11Z 82 120 2×40 79 11
VR4‑160H×15Z 106 160 3×40 107 15
VR4‑200H×19Z 130 200 4×40 135 19
VR4‑240H×23Z 154 240 5×40 163 23
VR4‑280H×27Z 178 280 6×40 191 27
VR4‑320H×31Z 202 320 7×40 219 31
VR4‑360H×35Z 226 360 8×40 247 35
VR4‑400H×39Z 250 400 9×40 275 39
VR4‑440H×43Z 274 440 10×40 303 43
VR4‑480H×47Z 298 480 11×40 331 47
VR6‑100H×7Z 56 30 15 100 1×50 25 14.4 6 M6 5.2 9.5 5.2 3.2 6 72 6 10 7 –7 3.78 3.78 1.5
VR6‑150H×10Z 96 150 2×50 102 10
VR6‑200H×13Z 136 200 3×50 132 13
VR6‑250H×17Z 156 250 4×50 172 17
VR6‑300H×20Z 196 300 5×50 202 20
VR6‑350H×24Z 216 350 6×50 242 24
VR6‑400H×27Z 256 400 7×50 272 27
VR6‑450H×31Z 276 450 8×50 312 31
VR6‑500H×34Z 316 500 9×50 342 34
VR6‑550H×38Z 336 550 10×50 382 38
VR6‑600H×41Z 376 600 11×50 412 41

DKS is a company specializing in the management of THK bearing. It has a large inventory and supports product customization. If the model you need is not found on the website, you can contact our company.
