HIWIN EGH30CAZ0H Linear Guideways
| Dimensions | |||
|---|---|---|---|
| H | Total height | 42 | mm |
| H1 | 10 | mm | |
| N | 16 | mm | |
| W | Block width | 60 | mm |
| B | 40 | mm | |
| B1 | 10 | mm | |
| C | 40 | mm | |
| L1 | 70,1 | mm | |
| L | Block length | 98,1 | mm |
| K1 | 21,05 | mm | |
| K2 | 6 | mm | |
| G | 12 | mm | |
| M | M8 | ||
| l | 12 | mm | |
| T | 9 | mm | |
| H2 | 8 | mm | |
| H3 | 9 | mm | |
| Mm | Mass | 0,76 | kg |
| Load ratings and torques | |||
|---|---|---|---|
| Cdyn | Dynamic load rating linear guideway | 23.700 | N |
| C0 | Static load rating of the linear guideway | 47.460 | N |
| MX | Dynamic moment | 339 | Nm |
| MY | Dynamic moment | 274 | Nm |
| MZ | Dynamic moment | 274 | Nm |
| MX | Static moment of the linear guideway | 680 | Nm |
| MY | Static moment of the linear guideway | 550 | Nm |
| MZ | Static moment of the linear guideway | 550 | Nm |
Related models：
CGW45HCZAH CGW45HCZBH CGW45HCZBP CGW45HCZBSP CGW45HCZBC
As a professional Linear Motion Guide supplier, we are mainly responsible for the global sales and technical services of HIWIN products. Our warehouses are located in HongKong and ShenZhen City, it is very convenient for demands of global market . Because there are many types of HIWIN products, we can not upload all of them at present. If you have any demand, you can directly contact us.
